DSH-LX

• Vin: 8-20V
• Current: ~ 100/350 mA
• Brightness: ~ 750 nits
• Protection: PPTC Fuse,  ESD, over voltage and reverse polarity

• TFT 800×480 ( 5" & 7")
• Capacitive Touch
• 2 NTP input
• 2 0-5v input
• 1 tacho input
• 30 Configurable sensors
• 6 different Screens
• Canbus 2.0b (128~1Mbit)
• RS232 Interface ( Ecumaster Classic )
• OBD via Wireless adapter
• SD Logging
• Configurable via LCD or Webpage

Not all the functions are avaiable at the same time, contact us for more info.
